9 Spindles Glass Straight Line Edging Machine Multistage PLC Control

Name: 9 Spindles Glass Straight Line Edging Machine Multistage PLC Control
Brand: FOSHAN STAR
Price: 13000 USD

Model Number : ST-11.353A

Wheels : 9

MOQ : 1

Delivery Time : 30 working days

Total dimension : 6600*1000*2600mm

Max arris width : 2.5mm

Price : $13000-$16000USD/SET

Total weight : 2800KG

Certification : CB,CE, RoHS, ISO9001

Working speed : 0.6-8.0m/min

Payment Terms : T/T

Glass thickness : 3-20mm

Supply Ability : 60Set each month

Bevel angle : 0°-45°

Brand Name : FOSHAN STAR

Name : Glass Straight Edging Machine

Packaging Details : Protective Film

Place of Origin : China

Total power : 22kw

Contact Now

9 Spindles Glass Straight Line Multistage Edging Machine, Variable 0‑45° Bevel With PLC Control

Machine Introduction

It performs glass edge grinding and polishing with 0°‑45° adjustable bevel angle.
Chain‑type conveyor with special elastic rubber pads and timing‑belt glass feeding ensures stable operation.
Features easy operation, convenient maintenance and automatic glass‑thickness adjustment.

Product Advantage

The main transmission is equipped with a variable‑frequency drive unit, delivering shake‑free, stable operation and low‑noise performance at both high and low speeds.
Comes with a digital readout for glass‑thickness monitoring.
Fitted with a manual oil‑lubrication mechanism, which simplifies servicing for the sliding bases supporting the grinding spindles.
The final motor dedicated to bottom‑edge polishing adopts a dual‑speed configuration.
Four‑layer waterproof brush assembly, convenient for dismounting and replacement.
Redesigned front‑rail structure enables quick removal and replacement of the glass‑thickness‑adjustment lead screw.

Techinical Parameters

Parameter	Value
Wheels	9
Working speed	0.6-8.0m/min
Max. arris width	2.5mm
Min. glass size	80*80mm
Glass thickness	3-20mm
Bevel angle	0°-45°
Max arris width	2.5mm
Total power	22kw
Total dimension	660010002600mm
Total weight	2800kg

Product Service

9 Spindles Glass Straight Line Edging Machine Multistage PLC Control

Product Images

9 Spindles Glass Straight Line Edging Machine Multistage PLC Control
